• Dimensions of main unit (approx.): 358m (Length)×125mm (Width)×399mm (Height)

•  Net weight of main unit (approx.): 7.8kg (no probe included

• Power supply voltage: Auto adaptable for AC100-240V

•  Power supply frequency: 50-60 Hz

•   Power consumption: 150 VA

• Control panel
• Alphanumeric keyboard
• 8 STC Slides
• Interactive backlit keys
• High resolution color LCD
• Diagonal dimension: 15 inch
• Resolution: 1024X768
• Brightness adjustment
• Integrated speaker
• Volume adjustable

• Abdominal
• Small organ
• Peripheral Vascular
• Transvaginal
• Transrectal
• Musculo-skeletal
• Pediatric
• Fetal
• OB
• GYN
• Urology

•  Electronic convex

•  Electronic linear

•  Electronic micro convex

• Convex transducer: C3-E
• Linear transducer: L7-E, L12-E, L7W-E,
• Transvaginal transducer: V6-E, V7-E
• TransRectal transducer: L7R-E
• Micro-convex transducer: MC3-E, MC6-E, MC5-E

• Logo
• Hospital name
• Exam Date/Time
• Mechanical index
• Tissue thermal index
• Patient Name and Patient ID
• System status (real-time or frozen)
• Gray/Color bar
• Cine guide
• Measurement summary window
• Measurement results window
• Probe type
• Frequency
• Menu indication
• Trackball functions indication
• Imaging parameters

• B Mode
• B/M Mode
• M Mode
• 2B Mode
• 4B Mode
• 2D Steer (option)
• CFM Mode
• CPA Mode
• DPD Mode
• PW Mode
• B/BC Mode (option)
• Triplex Mode
• Trapezoidal Mode
• Super Needle (option)

• High resolution 15 Inch LCD display
• 2 active probe ports
• Pulse Wave Doppler
• Color Doppler Flow Imaging
• Power Doppler Flow Imaging
• Directional Power Doppler Flow Imaging
• ≥500G integrated hard disk
• USB ports : 4
• Ethernet port :1
• S-video out port :1
• VGA port :1
• DVI port :1
• Foot switch :1
• Remote :1
• General measurement package
• Clinical measurement packages
• Multi-language screen display
• Review: images review system
• Archive: patient information management system
• Reporting system
• AIO (Automatic Image Optimization)
• Intelligent Zoom
• Speckle Reduction Algorithm (SRA)
• Q-Image software package

• DICOM (storage, print, worklist)
• Super needle
• B/BC mode
• 2D steer

• Convex transducer: C3-E
• Linear transducer: L7-E, L12-E, L7W-E
• Transvaginal transducer: V6-E, V7-E
• TransRectal transducer: L7R-E
• Micro-convex transducer: MC3-E, MC6-E, MC5-E
• Footswitch
• Carrying case
• Trolley

•     Video printer: SONY UP897MD, SONY UP-D711MD, SONY UP-X898MDLinear transducer: L7-E, L12-E, L7W-E
•     PC printer :
• HP Laser Jet 1020
• HP Laser Jet 1102/1102W
• HP Laser Jet P2055d
• HP Laser Jet M251n/M252n/252dw
• HP OfficeJet Pro 6230

• Gain
• STC
• Depth
• Freq.
• FHI
• AIO
• Invert
• X-CONTRAST
• UD Invert
• Zoom
• Full screen
• Focus number
• Compound
• SRA
• Density
• Dynamic
• Focus position
• Q-Image
• Persistence
• B Rejection
• Scan width
• Gamma
• Smooth
• Edge enhance
• Acoustic power
• L/R Flip
• Chroma
• 2D Map
• Zoom coef
• Trapezoidal imaging (only for linear transducer)
• 2D steer
• Biospy
• Super Needle
• Needle Angle
• Center Line

• Gain
• STC
• Depth
• Invert
• FHI
• AIO
• Full Screen
• Speed
• M Chroma
• Layout
• M 2D map

• Gain
• Depth
• FHI
• AIO
• Full Screen
• Freq.
• Wall filter
• Q-flow
• Color Invert
• Q-beam
• Steer (only for linear transducer)
• Color Map
• PRF
• Persistence
• Baseline
• Color mode: Velocity, Variance
• Wall Thre.
• Blood Effection
• Density
• B/BC

• Gain
• FHI
• AIO
• Full Screen
• Freq.
• Wall Filter
• Triplex mode
• Steer
• Invert
• PW chroma
• Audio
• PRF
• Speed
• Baseline
• Angle
• D 2D map
• Spectrum Enhance
• Dynamic Range

• Support 2D, M, PW, CFM, CPA, DPD
• Simultaneous and independent review in Triplex mode
• Cineloop auto/manual
• Variable cine playback speed
• User-define start and end frame of cine storage
• User-define start and end frame of cine review
• Storage in hard disk and display in real-time modes
• Slide show: slide show function



• ≥500GB integrated hard drive
• USB driver
• Still images storage format: BMP
• Still images export format: BMP, JPG
• Cine loops storage format: CINE
• Cine loops export format: AVI

• Image review Layout：1×1,2×2, 4×4
• Image management

• Patient info
• Review report
• Backup exam
• Restore exam
• Send exam
• Delete exam
• Patient view
• Study view
• Expand all
• Collapse all
• Select all
• New Exam
• Continue Exam
• Edit Exam
• Review

- Software packages for various specific clinical use

- Comprehensive analysis methods

- Clinical analysis reports

General measurement package

General B mode measurement

-Distance

-Perimeter/area

-Volume(1Distance)

-Volume(1Distance)

-Volume(1Ellipse)

-Volume（2Distance）

-Volume（3Distance）

-Volume(1Distance1Ellipse)

-Ratio(distance/ area)

-Angle

-Histogram(rectangular/ellipse/trace)

-profile

PW mode measurement

-Distance

-Peak

-Velocity

-Trace

-StD%

-StA%

-ICA/CCA

-Flow Volume

-Heart＿Rate

General M mode measurement

-Velocity

-Distance

-Time

-HR

• Abdomen
• Obstetric
• Gynecology
• Cardiology
• Vascular
• Urology
• Small parts
• ORTH
• Pediatrics

• Customize hospital information
• Customize language
• Customize screen type
• Customize screen controller
• Customize measurement package
• Customize comment/bodymark
• Customize exam mode
• Customize hotkey functions
• DICOM setting
• Net setting
• System information
• function setting
• hardware function
• Video&VGA setting

By user-define function, users could customize user-define preset, including

• Applications name, Presets name, User defined name
• Applications exam type
• Imaging parameters

• English
• Chinese
• Other languages

Note: other languages for detailed, please contact CHISON.

• System power in: 1
• Ethernet: 1
• S-video: 1
• Footswitch port: 1
• USB port: 4
• Video out: 1
• Remote control: 1
• VGA: 1
• DVI: 1
• ECG port: 1

• Ambient temperature: 10°C to 40°C
• Relative humidity: 30% to 75%
• Atmospheric pressure: 700 hPa to 1060 hPa

• Ambient temperature: -5°C to 40°C
• Relative humidity: ≤80%
• Atmospheric pressure: 700 hPa to 1060 hPa

Not all features or specifications described in this document may be available in all probes and/or modes.
